The MINI type Glass Manipulator is a compact glass robot with more lifting capacity. The unique feature of this lift is the slim frame width of only 620 mm(25 in). The rear wheel drive makes it very maneuverable with a tight turning radius.
Electric: Boom up/ down; Arm extend/ retract; Frame tilt up/ Down; Side-shift Left/ Right; Move
Manual: Rotation/ Side-Turning
info@ruyi-lift.com
Parameters
| Glass Manipulator | / | RYG-M |
| Load Capacity | Kg | 200 |
| Rotation | 。 | 手动360° Manual |
| Max. Lifting Height | mm | 2750 |
| Operation | / | Walkie Type |
| Battery | V/A | 2*12/35 |
| Charger | V/A | 24/8 |
| Driving Motor | V/W | 24/750 |
| Lifting Motor | V/W | 24/1500 |
| Width | mm | 620 |
| Length | mm | 2350 |
| Front Wheel Size/ QTY | mm | 300*80/2 |
| Rear Wheel Size/ QTY | mm | 210*70/1 |
| Pads Size/ QTY | mm | 250/4 |
| Side———-shift | / | 左右各50 L+R |
